Product Description
The SxS Refrigerator Ice Maker Assembly receives water from the water inlet, holds the water in the ice mold until it freezes and then automatically ejects the ice and refills again until the ice storage bin is filled. This part is compatible with all side-by-side Whirlpool®, KitchenAid® and Roper® plastic-liner refrigerators manufactured from 1984 -1993 with 28" or 31" in W cabinets. The assembly includes (1) wiring harness, (1) ice bin assembly, (2) mounting clips and installation instructions. Installing this part will require basic hand tools, some disassembly of the refrigerator and novice repair experience. You must unplug the refrigerator or shut off the house circuit breaker for the appliance before installing this part. Helpful Tip: This assembly does not include the front cover, wire harness or shut-off arm; we recommend that you use these parts from the old ice maker. Recommended Items: You may also need to purchase a new Water Line Installation Kit (item 1176515) and Water Filter (item 1603265) to properly install this assembly.
Equivalent Part Numbers: 1018, 1018, 8239, 8239, 8550, 8550, 944804, 944804, 1108106, 1108106, 1108154, 1108154, 1114209, 1114209, 1118766, 1118766, 1127599, 1127599, 1129303, 1129303, 1129306, 1129306, 1129318, 1129318, 2155184, 2155184, 2155185, 2155185, 2155186, 2155186, 2155187, 2155187, 2155188, 2155188, 1129316VP, 1129316VP, AP3062348, AP3062348, ECKMF83, ECKMF83, ECKMF86, ECKMF86, ECKMF90, ECKMF90, KIMS8, KIMS8
The Whirlpool 1129316 ice maker assembly is a genuine OEM replacement component designed to support ice production in your appliance or equipment.
This part helps maintain reliable appliance performance and supports the overall function of the system it serves. If this part becomes worn or stops working correctly, symptoms may include reduced ice production, irregular ice harvesting, or no ice output. Replacing a failed or worn component with the correct genuine OEM part can help restore proper operation and support consistent day-to-day performance.
Using genuine OEM Whirlpool parts ensures compatibility, reliability, and long-lasting performance. OEM components are built to the exact specifications of your equipment, protecting your investment and reducing the risk of costly breakdowns.
